Danplex HT-EP-2

Download Sheet

Performance Levels: Meets and exceeds :

DIN-51825-KP1N-20, DIN-51825-KP2N-20. ASTM-D-4950 LB-GC or higher

Description :

Danzol Danplex Lithium Complex (LithPlex) is a family of high temperature, extreme pressure greases formulated to meet most demanding automotive and industrial needs. The LithPlex ranges include HT-EP 00, HT-EP 0, HT-EP 1 and
HT-EP-2

Lithium Complex (LithPlex) HT-EP :

Danzol Danplex Lithium Complex soap grease for almost any application. Excellent water resistance, excellent shear stability and longer life. Danplex is a grease of choice for heavy load, extreme pressure and high temperature applications.

Typical properties :

PROPERTY ASTM HT-EP-00 HT-EP-0 HT-EP-1 HT-EP-2 HT-EP-3
NLGI Grade D217 00 0 1 2 3
Penetration (Worked 60 Stroke) D217 400-430 355-385 330@25°C 280@25°C 240@25°C
Thickener Declared Lithium Complex
Color Visual Blue/Green/Amber Blue/Green/Amber Blue/Green/Amber Blue/Green/Amber Blue/Green/Amber
Base Oil Declared Mineral Blend Mineral Blend Mineral Blend Mineral Blend Mineral Blend
Base Oil Viscosity cSt@40°C D445 220 220 220 220 220
Temperature of Use D2265 150°C Max** 150°C Max** 150°C Max** 150°C Max** 150°C Max**
Melting Point D566 >225°C >230°C >250°C >260°C >260°C
Odor Visual Agreeable Agreeable Agreeable Agreeable Agreeable
Non-Corrosive D1743 Pass Pass Pass Pass Pass
Water Washout 80°C, %, max D1264 <5 <5 <5 <5 <5
Four Ball Wear scar dia, mm, max D2266 0.4 0.4 0.4 0.4 0.4
Four Ball EP Weld point, kg, min D2596 NA NA 315 315 315
Oil Separation mass %, max D1742 NA NA <5 <5 <5
Storage Temperature* Declared 25°C 25°C 25°C 25°C 25°C
Shelf Life* Declared 5 Years* 5 Years* 5 Years* 5 Years* 5 Years*
Pumpability (Long distance) Declared Excellent Excellent Good Fair No

*Stored at room temperature and unopened container.

** up-to 150-170°C: bearings operating near their maximum recommended temperatures, re-greasing intervals should be reviewed.

Advantages :

High Temperature/Extreme pressure grease for highly loaded ball, roller, plain bearings and machines running at high temperatures. Extended service life even at continuous high temperature such as automotive disk and drum brakes, steel, cement and chemical industries.

Suitable for automotive and industrial machines, bearings, marine, agricultural, mining, construction machinery, pumps, conveyors, elevators, chains, pulleys, cranes, shafts, automotive applications where excellent water resistance and excellent thermal stability required.

Packaging :

0.5 KG                   plastic or metal can (Carton of 24 pcs)

1 KG                       plastic or metal can (Carton of 12 or 24 pcs)

2 KG                       plastic pail

5 KG                       plastic pail

15 KG                    plastic or metal pail

20 KG                    metal pail

180 KG                  metal drum

×
